POS Enabled
Nexus Family
Three Sizes
Android w/ GMS
Touchscreen Computers
Nexus 21.5” | Touchscreen Computer
| TECH TYPE | ANDROID | WINDOWS |
|---|---|---|
| CPU/PROCESSOR | MediaTek8390 (w.GMS) / G700 up to 2.2 Ghz | Intel® Celeron® J6412 up to 2.6 Ghz |
| MEMORY | 8GB DDR4 | |
| STORAGE | 128 GB eMMC | |
| SUPPORTED OS | Android 13 w. GMS (Google Mobile Services) + ESPER Seamless | Windows 10 IoT, Windows 11 PRO, Linux, Android 13 |
| I/O PORTS | 4 x USB 2.0, 1 x USB-C 3.0 (w. video), 1 x custom miniDP (convertible to HDMI or VGA), 1 x Serial RJ45/DB9 w. power delivery, 1 x LAN RJ45, 1 x Cash Drawer RJ11, 1 x Power Connector (DC-IN barrel connector) | 2 x USB 3.0, 2 x USB 2.0, 1 x USB-C (data only), 1 x custom miniDP (convertible to HDMI or VGA), 1 x Serial (RJ45/DB9) w. power delivery, 1 x LAN RJ45, 1 x Cash Drawer RJ11, 1 x Power Connector (DC-IN barrel connector) |
| WIRELESS CONNECTIVITY | WiFi-6, Bluetooth 5.2 | (option) Intel® WiFi-6 , (option) Bluetooth 5.2 |
| AUDIO | 1 X 3 W Integrated Speaker | |
| POWER | 36 W / 12 V | |
| DISPLAY | 15.6” Widescreen (1920 x 1080) True-Flat PCAP Multi-Touch | |
| PERIPHERAL (OPTIONS) | 3-Track MSR (USB), 2D Barcode Scanner (USB), PIN Pad brackets, 11.6” or 15.6”, Rear Displays w. Touch | |
| WALL MOUNT | VESA, 75 x 75mm | |
| DIMENSIONS | 11.6” = 11.42” W x 7.66” H x 7.40” D , 15.6” = 14.69” W x 11.69” H x 7.40”D, 21.5” = 20.38” W x 12.18” H x 1.74” D | |
| ENVIRONMENT | Operating Temp: 32°F to 85°F (0°C to 35°C), Storage Temp: -4°F to 140°F (-20°C to 60°C), Humidity: 20% to 85% RH non-condensing, IP54 Dust & Water Proof |
