Experience unmatched performance with the fully customizable Pulse Ultra Widescreen. Featuring Intel® Celeron® J6412 and Intel® Core™ processors, it delivers powerful, lightning-fast performance to meet your business needs. The True Flat PCAP multi-touch HD display enhances employee efficiency and keeps customers engaged with stunning clarity. Customize your setup with memory options from 8GB to 32GB and a range of peripherals, including a customer-facing display, magnetic stripe reader, mounted barcode scanner, and fingerprint reader.
Slim & Sleek Design
- 11th Gen Intel® Elkhart & Tiger Lake CPU options
- Up to 32GB of high-speed DDR4 memory
- Available in 15.6” Display
Custom Configuration
- Optional 11.6” or 15.6” rear display
CPU / Processor
Intel® Celeron® J6412
Intel® Core™ i3-1115G4
Intel® Core™ i5-11135G7
Memory
8GB DDR4, up to 32GB
Storage
1 x 128GB drive (M.2 NVMe) (larger drives available)
Supported OS
Windows 10 IoT Enterprise
Windows 11 Professional
Windows 11 IoT LTSC
Linux
Android 13
I/O Ports
2 x USB 3.0, 2 x USB 2.0
2 x USB-C (J6412: 2 x data only, i3/i5: 1 x PD* & video,
1 x data only)
1 x custom miniDP (convertible to HDMI or VGA)
2 x DB9 Serial w. power option
1 x RJ45 Gigabit LAN
1 x RJ-11 Cash Drawer Port
1 x 4-PIN PSU Connector (w. latch)
(option) Powered USB: 1 x +12V or 1 x +24V
Display
15.6” Widescreen (1920 x 1080) 16:9
True-Flat PCAP Multi-Touch
Peripherals
3-Track MSR (USB)
HID global fingerprint reader (USB)
LCM 2×20 customer display (USB)
11.6” and 15.6” 2nd display with touch
2D Honeywell barcode scanner
Supports most common PIN pads available from Ingenico,
PAX, Verifone, IDTECH, and others
Dimensions & Weight
14.52” W x 11.5” H x 8.28” D
Default Configuration
| UB5E4A-C721D6 | Intel Celeron J6412, 4GB RAM, 128GB NVMe SSD, WIN 10 IOT LTSC, Standard Base |
| UB5E4A-206635 | Intel Celeron J6412, 4GB RAM, 128GB NVMe SSD, WIN 11 IOT LTSC, Standard Base |
| UB5E4A-E3C02B | Intel Celeron J6412, 4GB RAM, 128GB NVMe SSD, WIN 11 PRO, Standard Base |
| UB5G4A-AFB156 | Intel Core i3-1115G4, 4GB RAM, 128GB NVMe SSD, WIN 10 IOT LTSC, Standard Base |
| UB5G4A-47C630 | IIntel Core i3-1115G4, 4GB RAM, 128GB NVMe SSD, WIN 11 IOT LTSC, Standard Base |
| UB5G4A-B9E578 | Intel Core i3-1115G4, 4GB RAM, 128GB NVMe SSD, WIN 11 PRO, Standard Base |
| UB5H4A-6B3274 | Intel Core i5-1135G7, 4GB RAM, 128GB NVMe SSD, WIN 10 IOT LTSC, Standard Base |
| UB5H4A-5618F1 | Intel Core i5-1135G7, 4GB RAM, 128GB NVMe SSD, WIN 11 IOT LTSC, Standard Base |
| UB5H4A-77CAA1 | Intel Core i5-1135G7, 4GB RAM, 128GB NVMe SSD, WIN 11 PRO, Standard Base |
- Product Highlights
-
Slim & Sleek Design
- 11th Gen Intel® Elkhart & Tiger Lake CPU options
- Up to 32GB of high-speed DDR4 memory
- Available in 15.6” Display
Custom Configuration
- Optional 11.6” or 15.6” rear display
- Specifications
-
CPU / Processor
Intel® Celeron® J6412
Intel® Core™ i3-1115G4
Intel® Core™ i5-11135G7Memory
8GB DDR4, up to 32GB
Storage
1 x 128GB drive (M.2 NVMe) (larger drives available)
Supported OS
Windows 10 IoT Enterprise
Windows 11 Professional
Windows 11 IoT LTSC
Linux
Android 13I/O Ports
2 x USB 3.0, 2 x USB 2.0
2 x USB-C (J6412: 2 x data only, i3/i5: 1 x PD* & video,
1 x data only)
1 x custom miniDP (convertible to HDMI or VGA)
2 x DB9 Serial w. power option
1 x RJ45 Gigabit LAN
1 x RJ-11 Cash Drawer Port
1 x 4-PIN PSU Connector (w. latch)
(option) Powered USB: 1 x +12V or 1 x +24VDisplay
15.6” Widescreen (1920 x 1080) 16:9
True-Flat PCAP Multi-TouchPeripherals
3-Track MSR (USB)
HID global fingerprint reader (USB)
LCM 2×20 customer display (USB)
11.6” and 15.6” 2nd display with touch
2D Honeywell barcode scanner
Supports most common PIN pads available from Ingenico,
PAX, Verifone, IDTECH, and othersDimensions & Weight
14.52” W x 11.5” H x 8.28” D
- Configurations
-
Default Configuration
UB5E4A-C721D6 Intel Celeron J6412, 4GB RAM, 128GB NVMe SSD, WIN 10 IOT LTSC, Standard Base UB5E4A-206635 Intel Celeron J6412, 4GB RAM, 128GB NVMe SSD, WIN 11 IOT LTSC, Standard Base UB5E4A-E3C02B Intel Celeron J6412, 4GB RAM, 128GB NVMe SSD, WIN 11 PRO, Standard Base UB5G4A-AFB156 Intel Core i3-1115G4, 4GB RAM, 128GB NVMe SSD, WIN 10 IOT LTSC, Standard Base UB5G4A-47C630 IIntel Core i3-1115G4, 4GB RAM, 128GB NVMe SSD, WIN 11 IOT LTSC, Standard Base UB5G4A-B9E578 Intel Core i3-1115G4, 4GB RAM, 128GB NVMe SSD, WIN 11 PRO, Standard Base UB5H4A-6B3274 Intel Core i5-1135G7, 4GB RAM, 128GB NVMe SSD, WIN 10 IOT LTSC, Standard Base UB5H4A-5618F1 Intel Core i5-1135G7, 4GB RAM, 128GB NVMe SSD, WIN 11 IOT LTSC, Standard Base UB5H4A-77CAA1 Intel Core i5-1135G7, 4GB RAM, 128GB NVMe SSD, WIN 11 PRO, Standard Base - Resources
-
